Textile and Bedding Automation
Quilting, spinning, weaving and mattress lines. The world APE knows best.
Want the mechanism, not just the footage?
We wrote a full explainer for this category: Air Jet Weaving Machines. What the machine does, how it works, the numbers that matter and who buys one.
15 films
-
0:56 Textile and Bedding AutomationAn air jet loom running at 2,015 rpm
An air jet loom firing weft yarn across the fabric with a pulse of compressed air, over two thousand times a minute. There is no shuttle and nothing mechanical crossing the warp. Machines in this family reach roughly 1,350 weft insertions per minute in production, and the sound alone is worth the fifty seconds.
-
8:02 Textile and Bedding AutomationThe robot revolution comes to garment sewing
The Wall Street Journal follows the attempt to automate garment sewing, including the machines that can do it and the reasons most factories still use people. It is honest about what works and what does not. The best available reporting on why cloth is so much harder than steel.
-
6:02 Textile and Bedding AutomationAn automatic sectional warper winding a beam
A sectional warper builds a beam of thousands of parallel yarns, each under identical tension, because any variation shows up as a fault in the finished fabric hundreds of meters later. Karl Mayer automated the whole sequence. It is one of the least known and most important machines in textiles.
-
5:52 Textile and Bedding AutomationA multi-needle quilting machine with a panel cutter
A multi-needle quilter feeding straight into a panel cutter, so quilted fabric comes off the roll and leaves as stacked, sized mattress panels. Combining the two removes the buffer between them and a whole handling step. Six minutes of the exact machine combination that most mattress plants are built around.
-
5:33 Textile and Bedding AutomationPanel quilting on a mattress quilter
A chainstitch panel quilter running a full pattern across the width of the fabric, with the needle bar tracking a programmed path. Panel quilting is where the look of a mattress is decided, and the machine has to hold the pattern over hundreds of meters of material. Five clear minutes of it working.
-
5:13 Textile and Bedding AutomationNew mattress machinery running on the show floor
A walk through a set of mattress machines from one of the best known names in bedding equipment: quilting, panel cutting, border work and closing. Seeing the machines in sequence explains how a mattress is actually built, which almost nobody outside the industry knows. Useful context for the individual machine clips.
-
4:49 Textile and Bedding AutomationA rotor spinning machine turning fiber into yarn
A rotor spinning machine with 600 spinning positions, each rotor turning at up to about 148,000 rpm, and robots patrolling the length of the frame to repair broken ends automatically. Cotton goes in as sliver and comes out as wound yarn packages. It is a factory disguised as a single machine.
-
3:34 Textile and Bedding AutomationA 16-head mattress quilter at speed
The V16 uses sixteen fixed needles in a tight arrangement that shortens the thread path dramatically, letting it sew far faster than a conventional mattress quilter. Speed in quilting is limited by thread management more than by motors. This is the machine that made that clear to the industry.
-
3:07 Textile and Bedding AutomationA coiler making Bonnell mattress springs
Steel wire goes in one end and finished Bonnell springs come out the other, coiled, knotted and counted, with no human touching them. Spring coiling is one of the oldest automated processes in bedding and still one of the most satisfying to watch. The wire never stops moving.
-
3:00 Textile and Bedding AutomationA spreader laying fabric for the cutting table
An automatic spreader lays fabric ply on ply onto a cutting table, tensionless and perfectly aligned, so that a cutter can slice through a hundred layers at once. Get the spread wrong and every garment in the stack is wrong. Watching the roll unwind and reverse is deeply satisfying.
-
2:49 Textile and Bedding AutomationA mattress line running panel to finished cover
A mattress quilting machine running at production speed with the pattern head tracing a design across the full panel width. The needle bar movement is fast enough to blur. Bedding machinery rarely gets filmed well and this one does the job.
-
2:07 Textile and Bedding AutomationA fully automatic carded pillow line
Fiber is opened, carded, weighed and blown into pillow shells, then the shells are closed and stacked, all in one continuous line. Filling a pillow to a consistent weight is much harder than it sounds because fiber does not flow like a liquid. This line does it without an operator.
-
1:50 Textile and Bedding AutomationMulti-needle quilting with automatic hemming
A multi-needle quilting machine stitches a full mattress panel pattern in one continuous pass, then hands it to an automatic hemming station with no operator between them. This is the heart of every mattress factory on earth. MPT films it at floor level so you can watch the fabric feed and the needle bar work.
-
0:57 Textile and Bedding AutomationA needlepunch line turning loose fiber into felt
Needlepunch turns loose fiber into fabric with no weaving and no adhesive, by driving thousands of barbed needles through the web to tangle the fibers together. ANDRITZ shows the line running at speed. Every geotextile, filter felt and mattress pad you have ever touched came off a machine like this.
-
0:55 Textile and Bedding AutomationAn unmanned sewing workstation
A sewing workstation running with nobody at it: the machine feeds, positions, sews and stacks on its own. Soft goods have resisted automation longer than almost anything else because fabric moves unpredictably. Fifty-five seconds that shows the problem finally being solved.
